Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device

1
MOQ
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device
cechy Galeria opis produktu Poprosić o wycenę
cechy
specyfikacje
Dokładność: 0.1
Moc: 40kva
Klasa ochrony: IP55
Woltaż: 380 V
Kierunek wibracji: Poziomy pionowy
Siła: 20 KN
Przemieszczenie: 51 mm
Przyśpieszenie: 100G
MAX LOAD: 270 kg
Zakres częstotliwości: 3-3500 HZ
Prędkość znamionowa: 1,6 m/s
ciężar cewki ruchomej: 3,5 kg
Średnica cewki ruchomej: Φ150 mm
Znamionowa siła sinusoidalna: 3000 N
Znamionowa siła losowa: 3000 N
Podkreślić:

automatic bearing vibration tester

,

laboratory shaker table machine

,

vibration analysis testing device
Podstawowe informacje
Miejsce pochodzenia: Guangdong, Chiny
Nazwa handlowa: ASLI
Zapłata
opis produktu
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device
High-Precision Vibration Testing and Analysis Equipment for Bearings, Motors, and Mechanical Parts — Laboratory Shaker Table for Reliability, Fatigue, and Dynamic Performance Evaluation
Application
This automatic bearing vibration testing machine is a mechanical measuring instrument and laboratory shaker table primarily used for product vibration and shock environmental testing, environmental stress screening tests, and reliability tests. It serves industries including aerospace, communications, electronics, electrical, and home appliances. The platform meets various test specifications such as IEC, MIL-STD, JIS, and ASTM.
Technical Specifications
Model Rated Sine Force (N) Rated Random Force (N) Frequency Range (Hz) Rated Acceleration (m/s²) Rated Speed (m/s) Rated Displacement (p-p) mm Max. Loading (Kg) Moving Coil (Kg) Dimension of Moving Coil (mm)
ES-3300030003-350010001.6251003.5Φ150
ES-3a300030003-35004001.6401209Φ230
ES-6600060003-350010001.6251806.5Φ230
ES-6a600060003-350010001.65125012Φ230
ES-1010000100003-300010001.85127014Φ240
ES-2020000200003-300010001.85130030Φ320
ES-3030000300003-280010001.85145040Φ450
ES-4040000400003-280010001.85150050Φ450
ES-5050000500003-270010001.85175050Φ450
ES-6060000600003-270010001.85175060Φ450
ES-1001000001000003-250010001.851100090Φ450
ES-1201200001200003-220010001.851110090Φ500
ES-1601600001600003-210010001.8511500150Φ600
ES-2002000002000003-200010001.8512500200Φ650
ES-3503500003500003-170010001.8514500300Φ870
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device 0 Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device 1
Product Features
  • Flexible suspension system and straight line guide, strong bearing capacity, good guidance performance and high stability.
  • The static stiffness of the central load airbag is large, the dynamic stiffness is small, the bearing capacity is strong, and the dynamic performance is excellent.
  • Rapid self-examination diagnosis and chain protection, high safety and reliability.
  • The air bag isolating and damping device makes the vibrator do not need the special foundation, perfectly reproduces the vibration wave and reduces the vibration transmission.
  • Provide different use of horizontal and vertical expansion platforms.
  • It can be used with all kinds of vibration controllers, and the operation is simple.
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device 2
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device 3
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device 4
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device 5
Certification
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device 6
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device 7
Hot Products
Vibration Test System
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device 8 		Vibration Climatic Compo Set
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device 9 		Various Size Climatic Chamber
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device 10
Related Products
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device 11
Our Services
Warranty: One year free warranty for whole set machine, lifelong time maintenance.
Service: OEM service, Design service, Buyer label service.
After-sale service: Feedback within 2 hours after getting the call.
Company Information
Short introduction about ASLi factory:
Automatic Bearing Vibration Testing Machine | Laboratory Shaker Table & Vibration Analysis Device 12
